HC-SR04, Ultrasonic, Distance Sensor+ SainSmart Graphic LCD4884 Shield Review
HC-SR04, Ultrasonic, Distance Sensor+ SainSmart Graphic LCD4884 Shield Feature
- Ultrasonic Module HC-SR04 Distance Sensor automatically sends eight 40 kHz and detect whether there is a pulse signal back.
- The SainSmart Graphic LCD4884 Shield has one 5 degree joystick (using Arduino Analog Pin 0)
- Buy them TOGETHER and get at the REDUCE price. It is a big bargain!!!
HC-SR04, Ultrasonic, Distance Sensor+ SainSmart Graphic LCD4884 Shield Overview
The link bellow is the code for the LCD4884. Please download it if you need it.
https://s3-ap-northeast-1.amazonaws.com/sain-amzn/20/20-011-906/LCD4884s.rar
The SainSmart LCD4884 Shield provides 48x48 display. This LCD shield can apparently meet your needs to display much information. It can display English, Chinese, even images. It also integrates a 5 DOF joystick. The shield has 6 Digital IO and 5 Analog IO.This 3 pin connector has a temperature sensor which can help indicate the temperature.
The Ultrasonic Module HC-SR04 Distance Sensor are 4 pins : VCC , Trig, Echo, GND . So it's a very easy interface for controller to use it ranging. The all process is: pull the Trig pin to high level for more than 10us impulse, the module start ranging;finish ranging. If you find an object in front , Echo pin will be high level , and based on the different distance, it will take the different duration of high level. So we can calculated the distance easily :
Distance = ((Duration of high level)*(Sonic :340m/s))/2
Package Content:
1 SainSmart LCD4884 Shield
1 SainSmart HC-SR04 Distance Sensor
